    • 도시철도 전차선 시스템
HF-EMSG 450/750V
Application
Halogen Free Electric Metro Safe Guard Cables
It’s the cable which added the mechanical characteristics of NF F 63-826 in IEC 60245.
무독성(HF)을 요구하는 전기설비의 제어판넬용
Product properties
  • Nominal voltage
  • Testing voltage
  • 450/750V AC
  • 2.5KV AC
Fire performance in generally
  • Fire Resistant
  • Flame Retardant
  • Smoke density
  • IEC 60332-3
  • IEC 60332-1
  • IEC 61034
Material properties
  • 구분
  • Halogen Free
  • Flame Retardant
  • 내한온도
  • 내유성(100±1℃/24h)
  • 내오존성(96±1℃)
  • 고온절연저항(MΩ/km)
    (도체허용온도)
  • HKIV
  • -
  • IEC 60332-1
  • -
  • Poor
  • Poor
  • 0.009
    (70℃)
  • XHHW/SIS
  • -
  • IEC 60332-3(C)
  • -15℃
  • Poor
  • Poor
  • 0.011
    (110℃)
  • HF-EMSG
  • IEC 60754-1
  • IEC 60332-3(C)
  • -25℃
  • Good
  • No Crack
  • 0.011
    (110℃)
* 무독성, 내유성 및 내오존특성 우수
