    • 철도차량 케이블
SCSN
Application
It is an electronic beacon or transponder placed between the rails
of an Automatic Train Protection (ATP) system.
Product properties
  • Testing voltage
  • 2KV AC / 1min
Material properties
  • Resistance to oil
  • Flame retardant
  • KS C 3004 - 21
  • KS C 3004 - 29
Communication characteristics
1) Capacitance at 1Khz 75.3 pF/m
2) Characteristics impedance at 1Mhz 79.6±16 Ω
Typical Cross Sectional Drawing
  • SCSN 2 X 2.0SQ
  • SCSN 4 X 2.0SQ
