This specification covers the minimum requirements of the construction, properties, material, test
requirements and method of EPR insulated and CR sheathed flexible cables.

• Norminal voltage
• Testing voltage

• U0/U(Um)

• 600/1,000 (1,200)V AC
• 900V DC
• 3,5KV AC

• Flame Retardant

• IEC 60332-1

• Water absorption test on insulation

• IEC 60502-1-18-13

• Core
• EA
• 120

• Size
• ㎟
• 1.5

• Conductor
• Const.
• No./mm
• 30/0.25

• Dia.
• mm
• 1.58

• Thick
• of
• Insulation
• mm
• 1.0

• Thick
• of
• Sheath
• mm
• 4.5

• Nom.
• Overall
• diameter
• mm
• 57.9

• Tole-
• rance
• mm
• 2.9

• Conductor
• resistance
• at 20℃
• (Max.)
• Ω/km
• 13.70

• Insulation
• resistance
• at 20℃
• (Min.)
• MΩ-km
• 1,360

• Test
• Voltage
• kV
• 3.5

• Approx
• Cable
• Weight
• kg/km
• 4,310
